Miller – Multimatic® 235 Multiprocess Welder
An efficient multi-process welder curated for professionals and welders of all experience levels to grow skills in MIG, flux cored, stick, and DC TIG welding. Quick and easy setup allows operators to have faster uptime and weld with confidence.
| Brand | Miller |
|---|
19 People watching this product now!
Processes
Stick (SMAW)
TIG DC (GTAW-DC)
Flux Cored (FCAW)
MIG (GMAW)
Multiprocess
General Specifications
| Title | Multimatic® 235 Multiprocess Welder – 240V |
|---|---|
| Applications | Aluminum Welding |
| Amperage | 20 A – 235 A |
| Material Thickness | Mild Steel 24 ga. – 3/8 in. (TIG) Mild Steel 24 ga. – 3/8 in. (MIG) Mild Steel 16 ga. – 3/8 in. (Stick) Aluminum 18 ga. – 3/8 in (MIG) |
| Weldable Metals | Aluminum Stainless Steel Steel |
| Current Type | DC |
| Max Open Circuit Voltage | 54 VDC |
| Wire Feed Speed | 1.5 m/min – 15.2 m/min 60 m/min – 600 m/min |
| Rated Output | CV: MIG/Flux 170 Amps at 22.5 V, 60% duty cycle CC: Stick 150 Amps at 26 V, 60% duty cycle CC: DC TIG 180 Amps at 17.2 V, 60% duty cycle |
| Welding Mode | CC/CV |
| Portability | Handle(s) Running Gear / Cart (Optional) |
| Weld Output | CC / CV |
| Input Voltage | 208 V 220/230/240 V |
| Input Phase | 1-Phase |
| Input Hz | 50/60 Hz |
